BA AF D05033 MG MICRO DIGITAL SERVO, 4.9G

  • Model: BA-AF D05033MG
  • Shipping Weight: 0.1lbs
  • Units in Stock: 10
  • Manufactured by: Blue Arrow

$19.95

Description:

BA AF D05033 MG MICRO DIGITAL SERVO, 4.9g

Technical Details:

Control System: PWM Pulse Width Control
Processor: Digital IC
Required Pulse: 3 to 5 V Peak to Peak Square Wave
Working frequence: 1500 μs /333 Hz
Rotation angle sensor: Precision Potentiometer
Rotation: Left Rotation: 60° , Right Rotation: 60°
Voltage: 3.5V to 6.0V
Temperature Range: -20℃ to 60℃
Driver Type:
Operating Angle: 45 Deg. one side pulse traveling 400μs
Direction: Clockwise/Pulse Traveling 900μs-2100μs
Pulse Width Scope: 900-2100μs
Neutral pulse: 1500μs
Speed:(No-load ): 0.72sec/ 60° @ 4.2V
  0.51sec/ 60° @ 6.0V
Torque:(Stall Full load): 1.28 kg . cm @ 4.2V
  1.64 kg . cm @ 6.0V
Idle Current: 0.030 A/ 4.2V 0.030 A/ 6.0V
Running Current: 0.080 A/ 4.2V 0.090 A/ 6.0V
Stall Current: 0.210 A/ 4.2V 0.250 A/ 6.0V
Dead Band Width: 2μs
Motor Type:
Bearings: TOP Ball Bearing
Bearing Type: MR74 (4mm x7mm x2mm)


Gear Material: Cu + Chrome-Titanium alloy(7075)
Servo case: ABS
Plug:
Connector Wire Length: 90.00 mm
Connector Wire SPEC: OD0.8mm/16 x 0.08mm 3p x 90mm (Jst1.25)
Weight: 4.90 g
Dimensions (L x W x H): 20.00*8.00*19.50 mm






Add to Cart:


Product 7/22

 Previous
 Return to the Product List
 Next

This product was added to our catalog on Tuesday 22 June, 2021.
